Gemfan D63-5 Propeller

Product Overview

The Gemfan D63-5 is a high-efficiency 5-blade propeller engineered specifically for 63.5mm drones. Constructed from durable polycarbonate (PC), it features a 1.65-inch pitch and weighs approximately 1.76g per propeller, providing an excellent balance between flight efficiency, thrust output, and noise reduction.

Its optimized five-blade design improves low-speed thrust performance and flight smoothness, making it especially suitable for low KV motor setups. Designed with a reinforced hub and precise dynamic balance, the D63-5 ensures stable power delivery and smooth, controlled flight characteristics.

Recommended for use with 1105 motors (5500KV recommended).

Key Features

• 5-blade configuration for enhanced thrust and smoother flight

• Optimized design balancing efficiency and low noise output

• Reinforced hub structure for improved durability and stability

• Precision balanced for vibration-free performance

• Ideal for cinewhoop drones requiring stable and controlled flight

Applications

• 2.5-inch cinewhoop drones

• HD aerial photography platforms

• Indoor and cinematic FPV flying

• Smooth freestyle and cinematic flight applications

Features & Advantages

Enhanced Thrust and Stability

The five-blade configuration delivers stronger thrust at lower RPM, improving stability and control.

Low Noise Performance

Blade geometry is optimized to reduce noise while maintaining efficient airflow and consistent lift.

Optimized for Low KV Motors

Designed to perform efficiently with low KV motors, improving overall flight efficiency and control.

High-Strength PC Material

Made from durable polycarbonate, offering excellent impact resistance and long service life.

Stable Power Transfer

Reinforced 5mm hub ensures secure mounting and consistent power transmission.

Specifications

• Model: Gemfan D63-5

• Material: PC (Polycarbonate)

• Blade Count: 5 blades

• Prop Diameter: 63.5 mm

• Pitch: 1.65 inch

• Center Thickness: 5 mm

• Max Prop Width: 13 mm

• Center Hole: 1.5 mm (3-hole mount)

• Weight (per prop): Approx. 1.76 g

• Recommended Motor: 1105 (5500KV recommended)
