FLYSKY FS-G7P Radio Transmitter with FS-R7P RX

Specifications:

Brand Name: FlySky

Item Name: FS-G7P Radio Transmitter with FS-R7P RC Receiver

Package Size: 20.5*17*12cm



FS-G7P Radio Transmitter:

Model: FS-G7P

Material: Plastic

Frequency: 2.4GHz

Color: Black

Channel: 7CH

Model Type: Cars, Boats, robot

RF Frequency 2.4GHz ISM: 2.4G Protocol ANT

Maximum Power: <20dBm

Range: >300m (ground)

Reception Sensitivity: ≤-99dBm

Channel Resolution: 4096

Low voltage alarm: ＜ 4.2V /7.2V

Date Output: PWM/PPM/i-BUS/S.BUS

Input Power: 4-9V/DC

Battery: 1.5AA*4/2S Lipo(JST)

Charging port: None

Data Output Type: -C Interface

Charging Interface: NO

Antenna Type: Built-in Single Coaxial Cable Antenna

Display Mode 128*64 LCD(Black and White Dot Matrix Screen)

Online Update: FlySky Assistant Update  Distance: ≥300m(Ground)

Working Current: About 110mA/6V

Temperature range: -10 ℃ - + 60 ℃

Humidity range: 20% -95%

Dimensions: 136.4*111.8*197.5mm

Weight: 305g

Certification: CE, FCC ID: N4ZG7P00



Features:

Two-way data transmission: signal strength can be sent back. For the standard receiver, it supports the back transmission of the detected BVD battery voltage. The sensors such as speed, temperature and voltage are supported

Powerful mixer function: 5 groups of programming mixer + 1 group of steering mixer, track professional mixer (dual engine mixer) and 4WS crawler special mixer

Display in English and Chinese, meeting different user demands

Support the switching between the one-way and two-way communication modes

Two-in-one ESC parameters can be set



FS-R7P RC Receiver:

Model: FS-R7P

PWM Channels: 7

RF: 2.4GHz

Protocol:  ANT

Range: >300M(Ground)

Antenna:  Single  Antenna

Input Power:  3.5-8.4V

RSSI: Support

Data Output:  PWM

Temperature Range:  -10℃-+60℃

Humidity Limit:  20%-95%

Waterproof Level:PPX4

Online Update:  Yes

Dimensions:  35*23.3*13.3mm

Weight: 8g

Certification:  CE,FCC ID:2A2UNR7P00
