IFlight Taurus X8 V3 Frame Kit

The Taurus X8 V3 BNF Cinelifter Frame Kit is aimed towards carrying big payloads, offering a soft-damped

universal platform for DSLR or cinema cameras (Red Komodo, Zcam, BMPCC, etc).

Optimized CG through the adjustable camera and battery mount

Stable silicon-ball decoupled camera CNC mount

Redundant ESC and motor configuration

2kg max payload for various cinema and DSLR cameras

Lightweight Side Panels - Keep Your Rig Clean

March 25, 2023: This Frame kit is compatible with the DJI O3 air unit.

Product Name：Taurus V3 X8 HD Cinelifter Frame

Wheelbase: 320mm

Diagonal Distance：120 mm

Frame Dimension: L283*W393*H30 mm

Arm Thickness: 8mm

Bottom Plate Thickness: 3mm

Top Plate Thickness:3mm

Upper Plate Thickness: 3mm

Camera Plate Thickness: 3mm

Motor Mounting：19x19mm

VTX Mounting：30.5*30.5mm

Weight: 940grams (Included no TPU Parts)

1 x Taurus V3 X8 HD Cinelifter Frame

2 x 20x300mm battery strap (Color May Vary)

2 x 20x400mm battery strap (Color May Vary)

2 x 20x500mm battery strap (Color May Vary)

1 x Aluminum Quick Release Camera Clamp

1 x Taurus X8 Hardware Accessories Kit

1 x CNC Aluminum Alloy Cam Mount

1 x DJI Air unit mount TPU

1 x 3d Printed Parts Kit

2 x Battery Pad

1 x LED mount

10 x Dampers

2 x Battery Anti-slip pads
