IFlight XING-E 3110 Cinelifter Motor

High-strength 5mm Steel shaft

N52H High-temperature magnets, NSK bearings

19x19mm hole pattern

Single strand copper winding

Hex bolt shaft set screw

Model: XING-E 3110 Motor

KV: 900KV

Weight(included wire): 75.8g

Dimension: φ36.4*25.4mm

Interphase Resistance: 81.9mΩ

Input Volts: 33.6V

Peak Current: 65.54A

Max Watt: 2143.8W

Mounting Holes: 19*19 φ3mm

Rotor Specifications:  Unibell

Shaft Diameter: 5mm

Shaft Protruding Length: 15mm

Lead: 260mm/18AWG

Magnet: N52H Curved

Configuration: 12N14P

Bearing Type: Dahua

Bearing Specification: φ11*φ5*5

Winding: Single Strand copper winding

1 x XING-E 3110 900KV Brushless Motor

4 x M3x10 screws

1 x M5 Flange Nut
